Ціни на запчастини не вказані на сайті. Для уточнення ціни сформуйте та відправте замовлення або зателефонуйте менеджеру.

Прокладка турбокомпресора Cummins M11, QSM11 3088984.

Прокладка турбіни

Застосування: двигун Cummins M11, QSM11, BUHLER VERSATILE 2375/2400, HYUNDAI ROBEX 500LC-7

Оригінальний номер: 3088984

Виробник Cummins made in USA.

Gasket, Turbocharger

Прокладка турбокомпрессора Cummins M11 3088984
1 3088984 Gasket, Turbocharger 1
2 3095798 Stud 2
      4024822/3592783/3592782 Kit, Turbocharger Recon equivalent 4024822 NX
          3592783 Turbocharger 1
          3592782 Turbocharger 1 Serviced as 4024822.
3           3502231 Slinger, Oil 1
4           3592892 Screw, Hexagon Head Set 3
5           3504967 Washer, Plain 3
6           3519163 Screw, Drive 2
7           3521441 Seal, Split Ring 2
8           3522597 Pin, Roll 2
9           3527619 Dataplate 1
10           3527651 Plate, Cover 1
11           3528094 Baffle, Oil 1
12           3528096 Plate, Oil Seal 1
13           3528204 Nut, Regular Hexagon 2 1/4 – 28 UNF.
14           3528221 Ring, Retaining 1
15           3518004 Washer, Lock 3 M6.
16           3529372 Nut, Regular Hexagon 2 1/4 – 28 UNF.
17           3529852 Clamp, V Band 1
18           3532195 Spacer, Mounting 3
19           3532940 Screw, Hexagon Head Set 3
20           3533038 Shield, Turbocharger Heat 1
21           3534109 Collar, Thrust 1
22           3534833 Bearing, Turbocharger 2
23           3595763 Clamp, V Band 1
24           3535575 Housing, Tur Bearing 1
25           3593629 Impeller, Tur Compressor 1
26           3535983 Shaft & Wheel 1
27           4040639 Bracket, Actuator 1 Serviced as mult kits.
28           3591209 Housing, Compressor 1
29           3591655 Bearing, Tur Thrust 1
30           3597518 End, Adjusting Link 1
31           3592780 Actuator, Turbocharger 1
32           3592777 Housing, Turbine 1 Serviced as 4030604.
33           3709510 Ring, Retaining 4
34           3723863 Ring, Retaining 1
35           3758848 Seal, Split Ring 1
36           3760250 Nut, Lock 1 M8 X 1.25.
37           3762915 Seal, O Ring 1
38           3818824 Nut, Hexagon Flange 4 M10 x 1.50
4001727 Valve, Pressure Regulator 1
39       68138 Connector, Male 1
40       103303 Plug, Pipe 1 1/8 NPT.
41       129768 Spring, Valve 2
42       129888 Seal, Rectangular Ring 2
43       3015521 Ball 2
44       3054609 Solenoid 2 Serviced as 4024809.
45       4088595 Screw, Socket Head Cap 8 M5 x 0.80 x 16
46       3348060 Shield, Shutoff Valve 2
47       3348687 Body, Control Valve 1
48       3406784 Plug, Orifice 1
49       3406785 Plug, Orifice 1
50       3406794 Plug, Orifice 1
51       3406795 Plug, Orifice 1
52       3406881 Harness, Etr Cnt Mdl Wrg 1
53       3867641 Seal, O Ring 1
54       4001741 Disc, Valve 2
55       S 607 Washer, Lock 2 #10
4024809 Kit, Fuel Solenoid 1
      129888 Seal, Rectangular Ring 2
      3054609 Solenoid 1 Serviced as 4024809.
4030604 Kit, Pre-set Turbine Hsg
      3518004 Washer, Lock 3 M6.
      3527651 Plate, Cover 1
      3592777 Housing, Turbine 1 Serviced as 4030604.
      3759526 Screw, Hexagon Head Set 3 M6 X 1.00 X 12.
      4027469 Kit, Turbocharger Bracket
          3504967 Washer, Plain 3
          3532195 Spacer, Mounting 3
          3532940 Screw, Hexagon Head Set 3
          3591204 Bracket, Actuator 1 Serviced as mult kits.
      4030225 Kit, Wastegate Actuator
